Prokudin-Gorskii glass plate scans contain three vertically stacked monochrome exposures. I split each input into equal-height B, G, and R channel arrays, held B fixed, estimated separate G→B and R→B shifts, then formed an RGB image with np.dstack([R, G, B]).

The implementation uses Python 3, NumPy, and scikit-image. It saves the reconstructed image as a JPG and writes each channel displacement to out/alignment_results.txt.

For the small JPG inputs, I evaluated every integer displacement in a [-15, 15] window along both axes. Each trial applies np.roll to the moving channel and compares it with the fixed blue channel.

Both metrics produced equally good alignments on the three supplied small images. Because np.roll wraps pixels from one edge to the opposite edge, I scored only a cropped interior region. For JPGs, the crop removes 20 pixels on every edge before scoring; the chosen shift is still applied to the full-resolution channel.

Brute-force full-resolution search is too slow for the large TIF images. For these inputs, the pipeline first computes Sobel edge maps for the moving and reference channels. Edges remain more stable than raw brightness across differently exposed color channels, particularly for difficult images such as Emir.

1. Build the pyramid. Repeatedly downsample each edge map by 0.5 with anti-aliasing until the current smallest dimension is below 200 pixels.
2. Search the coarsest level. Start at zero displacement and perform a broad NCC search with a radius of 40 pixels.
3. Refine to full resolution. At every next level, double the prior shift and conduct a local NCC search with a radius of 8 pixels.
4. Construct the color image. Apply the final shift to the original full-resolution G and R channels—not the edge maps—and stack them with B.

At pyramid levels, NCC scores exclude a border of min(10, height // 20, width // 20) pixels. This leaves enough image structure for matching while eliminating misleading wraparound regions.

Large low-detail areas and repetitive patterns can yield a deceptively good score for the wrong displacement. Interior cropping, a bounded search window, and edge maps reduce this failure mode.

The first pyramid implementation failed because the border crop was too large—sometimes 70–80 pixels per side—and the search parameters were too narrow. Reducing the crop to 5–10 pixels, increasing the coarse search from ±30 to ±40, increasing local refinement from ±5 to ±8, and lowering the pyramid cutoff from 250 to 200 pixels improved convergence.

Implementation note: three_generations.tif could not be processed in the batch run and had to be run individually.
